Operating System

Shared Main Cabinet

Industrial Control Configuration

Shared Main Cabinet

CPU

Shared Main Cabinet

Memory

Shared Main Cabinet

Storage

Shared Main Cabinet

Internal Interface

Shared Main Cabinet

Functional Parameters (Functional Configuration)

Identification Method

Shared Main Cabinet Touch Screen

Scrap Port

Tools that can be repaired, need secondary processing, temporarily stored for sharpening or re-inspection

Sharpening Port

Concentrated recycling of damaged tools, expired tools, and irreparable tools

Physical Parameters (supports sub-cabinet 1 drag N)

Overall Dimensions

Height 1300* Width 720* Depth 600 (mm)

Single Grid Size

Height 200* Width 205* Depth 205 (mm)

Body Color

Standard white

Machine Net Weight

Approximately 120kg

Capacity Specifications

60 independent slots, standard configuration of 6 layers, with 10 slots per layer, and 1 independent compartment on each side

Product Inventory

The internal slots can accommodate up to 780 boxes/pieces (specifics depend on the specifications of the materials),

1 independent compartment on each side, capable of recycling 2 types of tools or specialized items

Product Types

End mills, taps/threading tools, CNC blades, other small tools/accessories, etc.

Delivery Method

Directly drop to the bottom for shipment

Power parameters

Rated power / voltage

60W; 200V

Operating environment

Working temperature

Indoor 0℃ ~ 60℃
